44 Sonata Series — Planning and Installation Manual
Section 2 — Planning Guide
In Single-Channel Mono Mode the Apex will address the signals as shown
in
Table 6 .
Table 6. Sonata-to-Apex Single-Channel Mono Mode Input Mapping
D25 AES Pair 25 Input 25 (L&R)
D26 AES Pair 26 Input 26 (L&R)
D27 AES Pair 27 Input 27 (L&R)
D28 AES Pair 28 Input 28 (L&R)
D29 AES Pair 29 Input 29 (L&R)
D30 AES Pair 30 Input 30 (L&R)
D31 AES Pair 31 Input 31 (L&R)
D32 AES Pair 32 Input 32 (L&R)
Sonata Input Connector Signal Name Apex Input
A1 AES Pair 1 Left Input 1
A1 AES Pair 1 Right Input 2
A2 AES Pair 2 Left Input 3
A2 AES Pair 2 Right Input 4
A3 AES Pair 3 Left Input 5
A3 AES Pair 3 Right Input 6
A4 AES Pair 4 Left Input 7
A4 AES Pair 4 Right Input 8
A5 AES Pair 5 Left Input 9
A5 AES Pair 5 Right Input 10
A6 AES Pair 6 Left Input 11
A6 AES Pair 6 Right Input 12
A7 AES Pair 7 Left Input 13
A7 AES Pair 7 Right Input 14
A8 AES Pair 8 Left Input 15
A8 AES Pair 8 Right Input 16
B9 AES Pair 9 Left Input 17
B9 AES Pair 9 Right Input 18
B10 AES Pair 10 Left Input 19
B10 AES Pair 10 Right Input 20
B11 AES Pair 11 Left Input 21
B11 AES Pair 11 Right Input 22
B12 AES Pair 12 Left Input 23
B12 AES Pair 12 Right Input 24
B13 AES Pair 13 Left Input 25
B13 AES Pair 13 Right Input 26
B14 AES Pair 14 Left Input 27
B14 AES Pair 14 Right Input 28
B15 AES Pair 15 Left Input 29
B15 AES Pair 15 Right Input 30
B16 AES Pair 16 Left Input 31
