Sonata Series — Planning and Installation Manual 43
Interfacing to Apex
In Locked Stereo Mode the Apex will address the channels as shown in
Table 5 .
Table 5. Sonata-to-Apex Locked Stereo Mode Input Mapping
C20 AES Pair 20 Left 20 Right 20
C21 AES Pair 21 Left 21 Right 21
C22 AES Pair 22 Left 22 Right 22
C23 AES Pair 23 Left 23 Right 23
C24 AES Pair 24 Left 24 Right 24
D25 AES Pair 25 Left 25 Right 25
D26 AES Pair 26 Left 26 Right 26
D27 AES Pair 27 Left 27 Right 27
D28 AES Pair 28 Left 28 Right 28
D29 AES Pair 29 Left 29 Right 29
D30 AES Pair 30 Left 30 Right 30
D31 AES Pair 31 Left 31 Right 31
D32 AES Pair 32 Left 32 Right 32
Sonata Input Connector Signal Name Apex Input
A1 AES Pair 1 Input 1 (L&R)
A2 AES Pair 2 Input 2 (L&R)
A3 AES Pair 3 Input 3 (L&R)
A4 AES Pair 4 Input 4 (L&R)
A5 AES Pair 5 Input 5 (L&R)
A6 AES Pair 6 Input 6 (L&R)
A7 AES Pair 7 Input 7 (L&R)
A8 AES Pair 8 Input 8 (L&R)
B9 AES Pair 9 Input 9 (L&R)
B10 AES Pair 10 Input 10 (L&R)
B11 AES Pair 11 Input 11 (L&R)
B12 AES Pair 12 Input 12 (L&R)
B13 AES Pair 13 Input 13 (L&R)
B14 AES Pair 14 Input 14 (L&R)
B15 AES Pair 15 Input 15 (L&R)
B16 AES Pair 16 Input 16 (L&R)
C17 AES Pair 17 Input 17 (L&R)
C18 AES Pair 18 Input 18 (L&R)
C19 AES Pair 19 Input 19 (L&R)
C20 AES Pair 20 Input 20 (L&R)
C21 AES Pair 21 Input 21 (L&R)
C22 AES Pair 22 Input 22 (L&R)
C23 AES Pair 23 Input 23 (L&R)
C24 AES Pair 24 Input 24 (L&R)
