DIP Switches
DIP Switches
The Sonata AES-to-MADI converter has an 8-position dual in-line package
(DIP) switch that is located under a small cover on the rear panel. The cover
must be removed to access the DIP switches. Grass Valley recommends that
this cover should be in place during operation.
The DIP switch provides options for processes that are usually set during
installation and are not altered. The DIP switches affect all of the following
32 AES inputs:
Digital
AES to MADI
Table 15. AES to MADI DIP Switches (75 & 110)
MADI to AES
Table 16. MADI to AES Switches (75 & 110)
DIP Switch
Function
1
Only use 56 channels instead of 64. In 96K mode use 28 channels
instead of 32.
2
Force data to pass through the rate converters.
3
Force data to bypass the rate converters.
4
AES Samples are 20 bits instead of 24 bits.
5
Run in MADI 96 K mode.
6
When in 96K mode use 96K frame pattern instead of legacy pattern.
7
Not used.
8
LED test
DIP Switch
Function
1
Only use 56 channels instead of 64.
2
Not used.
3
Not used.
4
Not used.
5
Run in MADI 96 K mode.
6
When in 96K mode use 96K frame pattern instead of legacy pattern.
7
Not used.
8
LED test
