Sonata Series — Planning and Installation Manual 63
Outputs
Outputs
Table 27. M75 MADI-to-AES 75 Ohm Converter Output Specifications
Table 28. M110 MADI-to-AES 110 Ohm Converter Output Specifications
Table 29. MA MADI-to-Analog Converter Output Specifications
M75 MADI-to-AES 75 Ohm Converter
Connectors 32 AES/EBU 75-ohm BNC according to AES3id-2001.
Return Loss >20 dB 100 kHz to 12 MHz.
Output Level 1 V pk-pk into 75 ohms.
M110 MADI-to-AES 110 Ohm Converter
Connectors 32 AES/EBU 110-ohm according to AES3-2003 25 Pin 'D" connectors
using TASCAM pinout.
Return Loss >20 dB 100 kHz to12 MHz.
Isolation Transformer isolated and ground free.
Output Level > 3.5 V pk-pk into 110 ohms.
MA MADI-to-Analog Converter
Connectors 25 Pin "D" connectors according to TASCAM pinout. 8 channels each, split
for left and right channels. 32 Left channels inputs, 32 right channel inputs.
Output Impedance > 50 ohms differential typical.
Input CMRR > 90 dB @ 60 Hz.
Maximum Output Level +24 dBu (into 100K load).
Minimum Output Level 600 ohms or greater.
Output Levels for 0 dBFS output +24 to +10 dBu in 2 dB steps selectable by DIP switch, default +24 dBu.
Frequency Response +/- 0.2 dB 20-20kHz bandwidth ref 1kHz.
Gain Uniformity +/- 0.2 dB at 1kHz (Calibrated for a 100 K load impedance).
Crosstalk < -100 dB at 1kHz.
THD Full Scale < -90 dB or 0.0023% THD at 1kHz, 20-20 kHz bandwidth Full Scale.
Dynamic Range > 110 dB 20-20 kHz typical @ +24 dBu = 0 dBFS.
> 112 dB "A" weighted typical @ +24 dBu = 0 dBFS.
Resolution 24 Bit conversion.
Sample Rates Supported 44.1 kHz, 48 kHz, 88.2 kHz, and 96 kHz for all channels selectable by DIP
switch option as determined by the reference applied.
