GUIDE TO INSTALLATION AND OPERATION
32 | ADX-1901
Copy profile from
This line shows this ADX-1901 card, and identifies it by App server, Densité frame and slot number, card type and
firmware version.
The Profile column has a pulldown that allows you to select which profiles you will work with, and gives these choices:
• Current, User1, User2, User3, User4, User5, All
The Select column includes a checkbox (preselected checked) to confirm that you want to work with the current card.
Save Profile to Disk…
Click this button to open a Save dialog allowing you to specify a
file name and location to which the selected profiles for this
card will be saved.
Hint - It is a good idea to create a folder for these files, because
they are not explicitly identified as ADX-1901 profiles, and will
be difficult to find and identify if not clearly named and
conveniently located.
• Click the save button once the name and location have
been identified in the Save box
• If the file is saved correctly, the Transfer Status box on
the right of the Copy profile from line will indicate
Succeeded against a green background:
• If the file was not saved for some reason, the Transfer
Status box to the right of the Copy profile from line will
indicate Failed against a red background:
Restore profiles from disk…
Click this button to open an Open dialog box within which you
can locate and select a valid ADX-1901 profile file.
• Click Open to read the contents of the file and to
reconfigure this ADX-1901’s profiles according to its
contents
• While the reconfiguration is in progress, the Transfer
Status box on the right of the Copy profile from line will
indicate Working against a yellow background
• When the reconfiguration is complete, the Transfer Status
box on the right of the Copy profile from line will indicate
Succeeded against a green background
Copy Profile to
This line shows other ADX-1901 cards that are available on the
iControl network, each identified by App server, Densité frame
and slot number, card type and firmware version
Figure 5-29 Save Profile to Disk dialog
Figure 5-30 Restore Profiles from Disk dialog
