24 | ADX-1901
Coding
Mode
Program Channels
Left
Right
Center
LFE
Ls
Rs
1/0
X
2/0
X
X
3/0
X
X
X
3/0L
X
X
X
X
2/1
X
X
X
2/1L
X
X
X
X
3/1
X
X
X
X
3/1L
X
X
X
X
X
2/2
X
X
X
X
2/2L
X
X
X
X
X
3/2
X
X
X
X
X
3/2L
X
X
X
X
X
X
Measurements
The Measurements area displays results from the loudness measurements performed on the selected program
according to the settings made in the Loudness | Config tab and the Audio Programs panel. The three data boxes
show these values:
• True peak MAX
Maximum true peak level found in all selected input channels
• Momentary MAX Loudness averaged over a 400 ms sliding rectangular time window
• Short term (S)
Loudness averaged over the short-term time window
The chart shows a running plot of the last 15 seconds of the value of the Short Term (yellow trace) and Momentary
(green trace) loudness values. The bar graph at the right indicates the current Momentary value.
A reset, initiated by a user via the Reset button on the Loudness | Config tab, will reset all of these measurements.
About Log Files
Loudness logs contain data for a period of up to 24 hours. New log files are started:
• when the logging function is enabled
• every 24 hours after logging was enabled, until logging is disabled
• when the reference changes
• when the global config is changed,
See
_ANNEX_3_-ANNEX 3 - Loudness Logging and the Miranda Audio Loudness Analyzer
beginning on page 44
for detailed instructions on activating logging and analyzing the logged data files.
5.9 Alarms panel
This panel provides resources to set the detection conditions and card response for each of the alarms supported by
the ADX-1901.
5.9.1 Alarms – Video panel
Only one video alarm is defined.
