GUIDE TO INSTALLATION AND OPERATION
8 | ADX-1901
3 User Interface
3.1 Control options
The ADX-1901 can be controlled in three different ways:
• The local control panel and its push-buttons can be used to move through a menu of parameters and to adjust
parameter values (see section 4 ).
• Grass Valley’s iControl system can be used to access the card’s operating parameters from a remote computer,
using a convenient graphical user interface (GUI) (see section 5 ).
• Grass Valley’s RCP-200 panel (check for availability).
3.2 Card-Edge Status LED
The status monitor LED is located on the front card-edge of the ADX-1901, and is visible through the front access door
of the DENSITÉ frame. This multi-color LED indicates the status of the ADX-1901 by color, and by flashing/steady
illumination.
The chart shows how the various error conditions that can be flagged on the ADX-1901 affect the LED status.
• If a cell is gray, the error condition cannot cause the LED to assume that status
• If more than one LED status is possible for a particular error condition, the status is configurable.
See section 5.16 for details.
• The factory default status is shown by a 
The LED will always show the most
severe detected error status that it is
configured to display, and in the chart
error severity increases from left to
right, with green representing no
error/disabled, and flashing red the
most severe error.
If the LED is Flashing Yellow, it
means that the card is selected for
local control using the Densité frame’s
control panel. See
section 4.1 for
details.
Error Condition
LED Status
Green Yellow Red
Flashing
Red
Hardware failure 
No Rear 
SFP – Absence 
SFP – Type mismatch 
SFP – Temperature 1 
SFP – Optical Power 1 
SFP – Voltage 1 
SFP – Temperature 2 
SFP – Optical Power 2 
SFP – Voltage 2 
Video – Input video error 
Video – input Black Detect 
Video – Audio MTDT absent 
Metadata – SMPTE 2020 
Metadata – DVITC.ATC 
Audio – TP Overload CH1
Audio – TP Overload CH8


