Specifications
Serial Digital Fiber Outputs
Grass Valley SMV_SFP
Dual Transmitter Models Supported
(2 frequencies per CWDM device)
(see
for submodule
specifications)
SFP-1310-SDTX (1310nm)
SFP-CWDM-1 (1470nm & 1490 nm)
SFP-CWDM-2 (1510nm & 1530 nm)
SFP-CWDM-3 (1550nm & 1570 nm)
SFP-CWDM-4 (1590nm & 1610 nm)
Connector
4 LC
Fiber type
Single Mode 9/125 µm step index (SI) fiber complying with ITU-T
recommendation G.652, TIA/EIA-492CAAA, IEC publication 60793-2
and GR-20-CORE requirements.
Maximum attenuation of 0.4 dB/km @1310nm
Maximum attenuation of 0.3 dB/km @1550nm
Standard
Other than LC connector, conforms to SMPTE 297M-2006
Polarity
Non-inverting
Total jitter
≤ 0.2 UI p-p
Input to Output
Jitter transfer
< 1 dB peaking in jitter transfer function form 10Hz to 10 MHz
Intrinsic jitter
≤ 0.1 UI p-p
Electrical Length
Reclocked at 270 Mb/s
10 ns
Reclocked at 1.5 Gb/s
8 ns
Bypass
7 ns
Mechanical
Supported frame type
GeckoFlex
Environmental
Frame temperature range
Refer to GeckoFlex Frame Installation Manual
Operating humidity range
Non-operating temperature
Power
Power consumption
7.5 Watts
Table 6. 8935CF Specifications
Parameter
Value
