8916 Instruction Manual

8916 AES/EBU Auto-Tracking Delay DA

Installation

Installation of the 8916 module is a process of:

Placing the module in the proper frame slot, and

Cabling and terminating signal ports.

The 8916 module can be plugged in and removed from an 8900 Series frame
with power on. When power is applied to the module, LED indicators
reflect the initialization process (see

Power Up

on page 5

).

Frame Capacity

The maximum number of 8900 modules allowed in a frame is determined
by frame cooling capacity.

Table 1

provides the power capacity, cooling

capacity, and maximum module count for the 8916 in each frame type.

Note

Module capacity figures assume no other modules are in the frame.
If the maximum number of modules a frame can handle is less than ten,
provide as much space between the modules as possible.

Table 1. Power, Cooling, and Module Capacity of 8900 Frames

Capacity Calculated

8900T2

Frame

8900T2-F

Frame

8900TX

Frame

8900TF

Frame

8900TFN

Frame

Power (W)

60

60

100

100

100

Recommended Module Cooling (W)

30

60

30

90

90

8916 Modules

8

10

8

10

10
