8916 Instruction Manual 7
Power Up
PWR
(green)
Off No power to module or module’s DC/DC converter failed
On continuously Normal operation, module is powered
32 kHz
(green)
Off Sample rate is not near 32 kHz
On Continuously Sample rate is 32 kHz ±400 ppm
Flashing Sample rate is 32 kHz ±4%
44.1 kHz
(green)
Off Sample rate is not near 44.1 kHz
On Continuously Sample rate is 44.1 kHz ±400 ppm
Flashing Sample rate is 44.1 kHz ±4%
48 kHz
(green)
Off Sample rate is not near 48 kHz
On Continuously Sample rate is 48 kHz ±400 ppm
Flashing Sample rate is 48 kHz ±4%
REM OVR
(yellow)
Off Module configuration is by the module’s on-board switches and jumpers
On continuously
Module configuration is by remote control and on-board switches and jumpers are
overridden
Tracking
(yellow)
Off Fixed delay only
On continuously
Total operating delay is the sum of fixed and auto delay from frame sync delay input.
Front panel switches do not indicate total delay in this mode.
Table 2. Indicator LEDs and Conditions Indicated - (continued)
LED Indication Condition
