8916 AES/EBU Auto-Tracking Delay DA
Specifications
Table 3. 8916 Specifications
Parameter Value
Digital Input
Signal type AES3id (1995)/EBU and SMPTE 276M - transformer coupled
Number of inputs 1 loop-through
Connector type 75
Ω
BNC
Input return loss >25 dB (100 kHz-6 MHz)
Outputs
Number of outputs 7
Signal type AES3id (1995)/EBU and SMPTE 276M
Connector type 75
Ω
BNC
Return loss >25 dB (100 kHz-6 MHz)
Intrinsic Jitter <6 ns
Performance
Sampling rates 32 kHz, 44.1 kHz, and 48 kHz
On-board delay adjustment Minimum 2 ms, Maximum 510 ms
Minimum delay @ 32 kHz is 3 ms
Delay adjustment increments 2 ms
Tracking delay 20.8 µs to 30 ms
Environmental
Frame temperature range 0 to 45 degrees C
Operating humidity range 10 to 90% non-condensing
Non-operating temperature -10 to 70 degrees C
Mechanical
Frame type 8900 Series
Power Requirements
Supply voltage +12 V, -12V
Power consumption < 3.5 Watts
