Appendix
Terminal: Mini DIN 8-PIN
SERVICE PORT CONNECTOR
COMPUTER IN/S-VIDEO IN/COMPONENT IN/MONITOR OUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5 1 2 3 4
10 9 6 7 8
15 14 13 11 12
Configurations of Terminals
Red (R/Cr/S-C) Input/R Output
Ground (Horiz.sync.)
Green (G/Y/S-Y) Input/G Output
-----
Blue (B/Cb/---) Input/B Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
5V / ---
Horiz. sync. Input/Output
，Composite H/V sync.Input
Ground (Vert.sync.)
DDC data / ---
Ground
Vert. sync. Input/Output
DDC clock / ---
9
13
10
1
11
14
15
Serial
GND
R X D
-----
-----
-----
T X D
-----
4
1
3
2
5
6
7
----- 8
