Table of Contents
3
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its
respective corporation.
Features and Design . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . 3
To the Owner . . . . . . . . . . . . . . . . . . . . 4
Safety Instructions . . . . . . . . . . . . . . . 5
Air Circulation 6
Installing the Projector in Proper
Position 6
Moving the Projector 6
Compliance . . . . . . . . . . . . . . . . . . . . . 7
Part Names and Functions . . . . . . . . 8
Front 8
Back 8
Bottom 8
Rear Terminal 9
Top Control 10
Remote Control 11
Remote Control Battery Installation 1
Operating Range 1
Installation . . . . . . . . . . . . . . . . . . . . . . 13
Positioning the Projector 13
Adjustable Foot 13
Connecting the AC Power Cord 14
Connecting to a Computer 15
Connecting to Video Equipment 16
Connecting to Component Video and
RGB(Scart) Equipment 17
Basic Operation . . . . . . . . . . . . . . . . . 18
Turning On the Projector 18
Turning Off the Projector 19
How to Operate the On-Screen Menu 0
Menu Bar 1
Zoom and Focus Adjustment
Keystone Correction
Sound Adjustment 3
Remote Control Operation 3
Computer Input . . . . . . . . . . . . . . . . . 25
Input Source Selection 5
Computer System Selection 6
Auto PC Adjustment 7
Manual PC Adjustment 8
Image Level Selection 30
Image Level Adjustment 31
Screen Size Adjustment 3
Video Input . . . . . . . . . . . . . . . . . . . . . 34
Input Source Selection (Video) 34
Input Source Selection (S-Video,
Component, RGB Scart 1-pin) 35
Video System Selection 36
Image Level Selection 37
Image Level Adjustment 38
Screen Size Adjustment 40
Setting . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting 41
Maintenance and Cleaning . . . . . . . . 51
Warning Indicator 51
Cleaning the Air Filters 5
Attaching the Lens Cover 5
Cleaning the Projection Lens 53
Cleaning the Projector Cabinet 53
Lamp Replacement 54
Lamp Replacement Counter 55
Appendix . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting 56
Menu Tree 59
Indicators and Projector Condition 61
Compatible Computer Specifications 6
Technical Specifications 63
Optional Parts 64
Configurations of Terminals 65
PIN Code Number Memo 66
Dimensions 67
