Step 2: open the dome cover – ACTi Outdoor Dome on Tilted Wall User Manual
Page 4
Installation Guide
Step 2: Open the Dome Cover
1.
Remove the plastic covering the camera.
2.
Loosen the three (3) screws securing the dome cover.
3.
Carefully lift to open the dome cover and place it on the side of the camera.
NOTE:
Do not abruptly lift the dome cover; it is attached to the camera with a spring wire.
