Installation Guide
12
For more information on connecting these cables, please refer to the camera model
hardware manual downloadable from the website ( www.acti.com ).
2. Connect the network cable to the Ethernet port of the camera.
NOTE: For models with other connectors (e.g. power adaptor, DI/DO, etc.), connect the
cables to their corresponding connectors. Sample image below.
For more information on connecting these cables, please refer to the camera model
hardware manual downloadable from the website ( www.acti.com ).
Digital Input / Output
(DI/DO) Connector
12V Power Connector
Audio Input / Output
Connector
