Boarder Gateway 5800
- 5 -
3: Network2 Interface LED (not used)
4: H/D LCD
5: Power Switch
6: System Status LED
7: LCD Panel
8: LCD Touch Panel
Boarder Gateway 5800 Rear Panel:
Functions:
1: Electric Fan
2: AC Power outlet
3: AC Power switch
4: Keyboard/Mouse
5: Console port
6: SIP Service Ethernet port
7: Management Ethernet port
8: VGA
9: USB (not used)
9
1
2
3
4
5
6
7
8
