Page 4: Boarder gateway 5800 front panel, Welltech computer co., ltd, Functions: 1: power led, Network1 interface led (not used)
Welltech Computer Co., Ltd.
Boarder Gateway 5800
- 4 -
Application Example:
Hosted PABX Customer Side SBC
Hosted Call Center Customer Side VOIP Recording
Soft-Switch Server Side SBC
Lawful Interception for Soft-Switch
Architecture:
Boarder Gateway 5800 Appearance Description
Boarder Gateway 5800 Front Panel:
Functions:
1: Power LED
2: Network1 Interface LED (not used)
WellBG 5800 Applications
IP Phone
IAD
Class 5 Soft-Switch
VOIP
Core
Network
Internet
NATed
Private Net-
work
Private Net-
work
Private Net-
work
NATed
Private Net-
work
IAD
Soft-phone
Enable NAT Users
Auto RTP proxy
Plug and Play
Soft-Switch Protection
N+1 Redundant
WellBG 5800
WellBG 5800
IP Phone
IP Phone
1
2
3
4
5
6
7
8
