Chapter 4 - Signals and Troubleshooting
IV A
4 - 14
DCS 500B / DCP 500B Operating Instructions
Code
seven
segm.
display
Text on
LCD of control panel
CDP 31x
Definition /
Possible source
Signal
number
(ALARM_WORD_1/2)
Remark
A 127 Ext. FAN ack.alarm
Alarm No Acknowledge from External FAN (of
Motor)
Check: - See Fault Code
F 40.
11104
bit 15
A 128 Panel disconnected
Alarm No Communication with (Control)
Panel CDP 31x
No communicaiton is possible with the con-
trol Panel CDP 31x in REMOTE mode; the
alarm signal will disappear once communi-
cation is in order again.
11105
bit 0
A 129 Type code changed
Alarm Type Code (Hardware Code of Thyris-
tor Power Converter) changed
Unit type code stored in memory differs from
the hardware coding.
Check: - New control board SDCS-
CON-x?
- Control board SDCS-CON-x /
SDCS-PIN-xx board inter-
changed?
Action: - Save values in non-volatile
memory using BACKUPSTORE-
MODE
[11202]
;
see also Alarm Code
A 130.
11105
bit 1
A 130 Init values read,S2
Alarm Initializiation Values read into RAM
Default values have been loaded into the
RAM, e.g. using Jumper
S2
.
Signal will then often appear in conjunction
with Alarm Code
A 129
; but will not always
be shown on the unit's seven-segment dis-
play, though it will always be entered in the
Fault Logger.
11105
bit 2
A 132 Param set 2 missing
Alarm Valid Parameter Set 2 missing
Check: - Has - before activation of Param-
eter Set 2 (over [
P 913]
or
[P 11202]
) - the content of the
RAM been saved over
[P 11202]
,
Value 5 (SELECT_MOT2_SET)
in Motor Set 2?
11105
bit 3
