42
TRI TOOL INC.
92-1238 : Rev. 070126
Parts List, Model 648RBL Clamshell Sub-Assembly
Item Part
No. No. Description Qty
1. 19-0673 HOUSING, MAIN REF
2. 29-0300 BEARING 40
3. 33-1801 SCREW, SHOULDER 40
4. 34-0275 WASHER, THRUST 40
5. 35-0382 NUT, ADJUSTMENT 40
6. 39-0721 GEAR, HEADSTOCK REF
MODEL 648RBL CLAMSHELL SUB-ASSEMBLY
