Parts List, Model 648RBL Clamshell Sub-Assembly
Item Part
No. No. Description Qty
08-0337 BLOCK ASSEMBLY, CLAMP 4
1. 19-0659 HOUSING 1
2. 24-1242 PLATE, ADAPTER 1
3. 32-0043 PIN, ROLL 1
4. 33-0109 SCREW, CAP 4
MODEL 648RBL CLAMSHELL SUB-ASSEMBLY
