Tri Tool 620SB Clamshell Hydraulic - Manual (Page 51)

51
Model 620SB Low Profile Clamshell, Hyd.
92-0282 : Rev. 131230
Parts List, Tool Block (P/N 08-0169)
Item Part
No. No. Description Qty
1 30-0464 PLUNGER, BALL 1
2 33-0042 SCREW, CAP, 1/4-20 X 1 2
3 33-0043 SCREW, CAP, 1/4-20 X 1 1/4 10
4 33-0075 SCREW, CAP, 3/8-16 X 2 10
5 33-0287 SCREW, BUTTON, 1/4-20 X 3/4 2
6 33-0530 SCREW, SET, 3/8-16 X 5/8, CUP PT 3
7 33-0531 SCREW, SET, 3/8-16 X 3/4, CUP PT 9
8 33-1333 SCREW, SET, 3/8-24 X 1 1/2, HD 5
9 33-1338 FEEDSCREW ASSY 1
10 35-0204 NUT, FEED, 1/2-32 1
11 47-0445 BRACKET, TOOL MODULE 1
12 48-0309 BLOCK ASSY, TOOL 1
13 66-0043 RAIL, SLIDE 2
