Tri Tool 602TSB Clamshell Air - Manual (Page 37)

37
Model 602TSB
92-0139 : Rev.131230
Parts List, Model 602TSB Clamshell Sub-Assy (Ref: P/N 02-2039)
Item Part
No. No. Description Qty
1. 19-0293 HOUSING, MAIN 1
2. 24-0513 PLATE, THRUST 1
3. 24-0515 PLATE, BEARING BACKING 2
4. 24-0516 PLATE, BEARING BACKING 4
5. BAR ASSY, ADJUSTABLE 2
REFER TO ‘CLAMPING PADS’ FOR OPTIONS
6. BAR ASSY, FIXED 2
REFER TO ‘CLAMPING PADS’ FOR OPTIONS
7. 28-0057 SEAL, FELT 12”
(31 cm)
8. 28-0057 SEAL, FELT 16”
(41 cm)
9. 29-0171 BEARING, MAIN 1
10. 32-0008 PIN, ROLL, 5/64 DIA X 1/4
2
11. 32-0015 PIN, ROLL, 3/32 DIA X 5/16 2
12. 32-0153 PIN, DOWEL
2
13. 32-0211 PIN, ALIGNMENT 4
14. 33-0012 SCREW, CAP, 6-32 X 3/8 4
15. 33-0029 SCREW, CAP, 10-24 X 5/8
6
16. 33-0032 SCREW, CAP, 10-24 X 1 6
17. 33-0039 SCREW, CAP, 1/4-20 X 5/8 2
18. 33-0056 SCREW, CAP, 5/16-18 X 1
2
19. 33-1452 SCREW, SET, 5/16-24 X 5/8, HDOG 8
20. 39-0286 GEAR, HEADSTOCK 1
NOT SHOWN:
05-1081 SHIPPING KIT, 602TSB 1
36-0003 WRENCH, L, 3/32” HEX 1
36-0005 WRENCH, L, 1/8” HEX 1
36-0007 WRENCH, L, 5/32” HEX 1
36-0008 WRENCH, L, 3/16” HEX 1
36-0010 WRENCH, L, 1/4” HEX 1
36-0011 WRENCH, L, 5/16” HEX 1
36-0018 WRENCH, T, 1/8” HEX 1
36-0020 WRENCH, T, 5/32” HEX 1
36-0021 WRENCH, T, 3/16” HEX 1
36-0051 WRENCH, SPANNER 1
60-0042 LATHE STAND 1
86-0057 CARRYING CASE 1
