Model 602TSB
92-0139 : Rev.131230
SEVER AND BEVEL TOOL BIT SETS
Right Hand Sever and Bevel Tool Bit Sets have been designed to bevel the end of
the tube on which the Clamshell is mounted.
Right Hand Sever and Bevel Tool Bit Set
Right Hand Sever and Bevel Tool Bit Sets
Range
Max Wall
Thickness
Pipe or Tube
Material
RH Bevel
Tool Bit P/N
Sever Tool
Bit P/N
Right Hand Sever and 30° Bevel Tool Bits use with a Spacer (P/N 30-0699)
1.50" thru 2.00" OD tube .400" 10.2 mm CS, SS 99-2172 99-2173
