Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Lead Soldering Temperature T
SOLD
260 ºC
Lead Soldering Time t
SOLD
10 sec.
Supply Voltage V
CC
0 6 V
Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Ambient Operating Temperature T
A
0 70 ºC 1
Supply Voltage
OPT-1250x1xx
OPT-1250x2xx, OPT-1250x4xx
V
CC
4.75
3.135
5.25
3.465 V
Note:
1.See ordering information for detail
Electrical Characteristics
(At recommended ambient operating temperature, T
A
and supply voltage, V
CC
)
Parameter Symbol Min. Typ. Max. Unit Note
Total Supply Current I
CCT
310 mA
Transmitter
Transmitter Data Input Voltage-Low
V
IL
-V
CC
-1.810 -1.475 V 1
Transmitter Data Input Voltage-High V
IH
-V
CC
-1.165 -0.880 V 1
Transmitter Differential Input Voltage V
DT
0.3 1.6 V 2
Receiver
Data Output Voltage-Low
V
OL
-V
CC
-1.95 -1.62 V 1
Data Output Voltage-High V
OH
-V
CC
-1.045 -0.74 V 1
Receiver Differential Output Voltage V DR 0.5 0.7 1.2 V 2
Output Data Rise/Fall Time t
r
/t
f
0.4 ns 3
PECL SD Output
LOW level output voltage
HIGH level output voltage
V
SDL
-V
CC
V
SDH
-V
CC
-1.84
-1.1
-1.60
-0.9
V 4
TTL SD Output
LOW level output voltage
HIGH level output voltage
V
SDL
V
SDH
0
2 0.8
V
CC
V 5
Notes:
1. For OPT-1250A1F1x, OPT-1250A4F1x, OPT-1250B2Q1x and OPT-1250B1Q1x.
2. For OPT-1250A2F2x and OPT-1250B4Q2x.
3. These are 20%~80% values
4. For OPT-1250A1F1x, OPT-1250A2F2x, OPT-1250B1Q1x and OPT-1250B2Q1x
5. For OPT-1250A4F1x and OPT-1250B4Q2x
