FW-1884
Applications Guide
FireWire
Monitor
Subwoofer
Computer
Reverb
ADAT Input ADAT Output
Monitor Out 1-6
T his expanded system shows the FW-1884 with two
FE-8 fader packs for 24-fader control. Up to 15 FE-8s
can be added if you like to see lots of faders, and you
can always switch fader banks to control any number of
channels. The control surface is connected to a computer
running DAW software. Using 96kHz/24-bit A/D and D/
A converters, the FW-1884 offers full 96kHz operation on
all analog I/O channels with compatible DAW software.
You can even add an external A/D converter through
the ADAT optical input and a dedicated word clock
generator when you want the absolute best audio
recording possible.
The control room section can be run in 7.1-channel
surround mode, even generating stereo and surround
mixes simultaneously. You can bus your aux sends to
the line or ADAT outputs, returning external effects pro-
cessors to the line or ADAT inputs to supplement your
plug-in library. Insert your favorite compressors and EQs
into the line inputs for fl exible routing through your
DAW program.
You’ll appreciate the 100mm moving faders, switch-
able encoders, EQ control and dedicated edit commands
as you polish your work. When you’re fi nished mixing,
output to an external stem mixer or bounce back to hard
disk. Or do both, simultaneously.
96
kHz Surround Mixing
06/30/03 Pa
g
e
4
of 6
