FPGA Pinout
See board schematics.
Bibliography
1. C6000 Peripherals Reference Guide (literature number SPRU190)
Describes common peripherals available on the TMS320C6x digital signal processors. This book
includes information on the internal data and program memories, the external memory interface
(EMIF), the host port, multichannel-buffered serial ports, direct memory access (DMA), clocking
and phase-locked loop (PLL), and the power-down modes.
2.
TIM-40 MODULE SPECIFICATION Including TMS320C44 Addendum
3.
SHB Technical Specification
4.
SDB Technical Specificatio n
5.
TMS320C4x User's Guide (literature number SPRU063)
Describes the C4x 32-bit floating-point processor, developed for digital signal processing as well
as parallel processing applications. Covered are its architecture, internal register structure,
instruction set, pipeline, specifications, and operation of its six DMA channels and six
communication ports. Software and hardware applications are included.
6.
Xilinx Virtex-II datasheet and application notes
7. SMT6400 help file
