Version 1.0.2 Page 10 of 24 SMT361Q User Manual
EMIF Control Registers
The C6416 has two external memory interfaces (EMIFs). One of these is 64 bits
wide (EMIF_A), the other 16 bits (EMIF_B).
The C60 contains several registers that control the external memory interfaces
(EMIFs). A full description of these registers can be found in the
C6000
Peripherals Reference Guide .
The standard bootstrap will initialise these registers to use the following
resources:
Memory space
(EMIFA)
Resource Address range
Internal program memory
(1M) 0x00000000 - 0x000FFFFF
CE3 Virtex 0xB0000000 - 0xB00FFFFF
Memory space
(EMIFB)
Resource Address range
CE0 HPI of adjacent DSP 0x60000000 - 0x600000FF
CE1 8MB Flash in 4 pages
Page is selected with
GPIO9 and GPIO10
0x64000000 – 0x641FFFFF
CE2 Any access asserts FPGA
PROG line 0x68000000 – 0x641FFFFF
CE3 A write programs data bit
D0 serially in the FPGA and
make a CCLK edge. 0x68000000 – 0x641FFFFF
