Interrupts
SDB
The SMT361Q provides two SHB available to DSP_A that are 32-bit SDB.
They are numbered SDB_0 for SHB_A, SDB_1 for SHB_B.
SDB Clock selection
The SDB clock selection is not implemented. The clock is running at the EMIF speed
i.e. 100MHz.
Global bus
The SMT361Q provides one global bus interface available to DSP_A.
CONFIG & NMI
Only DSP_A has control over these bits.
Timer
Only DSP_A has control over the timer pins.
IIOF interrupt
The firmware allows DSP_A to generate pulses on the external interrupt lines of the
TIM.
