Function: Input Source to Output 2
Byte
Value
Description
1
F0H
System-Exclusive Message
2
00H
1
st
Byte of Studio Tech ID
3
00H
2
nd
Byte of Studio Tech ID
4
56H
3
rd
Byte of Studio Tech ID
5
03H
Product ID (Model 58)
6
09H
Function, Right Input Source
7
0nH
Input Source, range 1-8, 1=input source 1, 2=input source 2, etc.
8
nnH
Input Source Channel Status Bitmap
(sum values from all seven channels):
Channel 1: off=00; on=01
Channel 2: off=00; on=02
Channel 3: off=00; on=04
Channel 4: off=00; on=08
Channel 5: off=00; on=10
Channel 6: off=00; on=20
Channel 7: off=00; on=40
9
0nH
Input Source Channel Status
Channel 8: off=0; on=1
10
F7H
EOX, End of System Exclusive
Note:
Using this function requires the Model 58’s front-panel-mounted DIP switches to
be set as follows: Switch 5 to off (down) and switch 6 to on (up).
