Model 58/59 User Guide Issue 4, December 2000
Studio Technologies, Inc. Page 51
for Surround
Function: Monitor Output Level - Normal
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1 st Byte of Studio Tech ID
3 00H 2 nd Byte of Studio Tech ID
4 56H 3 rd Byte of Studio Tech ID
5 03H Product ID (Model 58)
6 03H Function, Monitor Output Level - Normal
7 nnH Monitor Output Level, MSB, range 00-7F
8 0nH Monitor Output Level, LSB, range 0-1
9 F7H EOX, End of System Exclusive
Notes: Control console sends new value each time monitor output level is changed.
Monitor output level is 8-bit precision, spread over two MIDI bytes: 00H 00H
lowest; 7FH 01H highest. MIDI byte 7 is monitor output level bits 2-8; MIDI
byte 8 is monitor output level bit 1.
Dim function is performed by control console and is sent using monitor output
level command.
This function is in effect only when monitor output channel status is on and bypass
status is normal.
