ENGLISH
TEATRO 80 - M80
ELECTRONICS
Input signals:
• 1 COMPOSITE VIDEO (CVBS)
gilded RCA type connectors
1.0 V
pp
/ 75 Ω, negative synchronisation
• 1 S-VIDEO (Y/C)
4 pin mini-DIN connectors
Y: 1.0 V
pp
/ 75 Ω, negative synchronisation
C: 0.286 V
pp
/ 75 Ω, [NTSC burst rated level]
0.3 V
pp
/ 75 Ω [PAL, SECAM burst rated level]
• 2 COMPONENTS (Y/Pr/Pb/) - RGBS
1 set of 4 RCA connectors
1 set of 5 BNC connectors
- Component signal
Y: 1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
YPrPb:0.7 V
pp
/ 75 Ω
- RGB Signal
R,B: 0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, HV synchronisation
1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Positive or negative TTL, 5 V
pp
/ 1 kΩ
• 2 RGBHV (RGB analogue)
female DB15HD-type connectors
R,B:0.7 V
pp
/ 75 Ω
G:0.7 V
pp
/ 75 Ω, separate H, V or HV synchronisation
1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Positive or negative TTL, 5 V
pp
/ 1 kΩ
• 1 DVI (RGB-YPrPb digital) connector DVI-D female
• 6 HDMI HDCP
• 1 HD-SDI (connector BNC)
Control:
Keypad on rear input panel, remote control,
via RS232 from PC or home automation
devices, USB 1.1, LAN RJ45
Horizontal frequency:
from 15 to 80 kHz (up to UXGA format @
65 Hz)
Vertical frequency:
48 -100 Hz, 24Hz @ 1080p
Video standard:
automatic selection (PAL B,G,H,I,M,N,60,
SECAM, NTSC 3.58 and 4.43)
Graphic standards:
VGA, SVGA, XGA, SXGA, UXGA
High definition standard:
ATSC HDTV (480p, 720p, 1080i, 1080p)
Colour temperature:
from 5500K to 9000K
Contrast:
>5000:1
Lamps:
2 of 300W (can be dimmed to 250W)
Outputs:
2 12V jack connectors (1 active when sys-
tem powered, 1 active when 16:9 aspect
ratio selected)
GENERAL PROJECTOR
Power cable:
(EU, UK and US); 2m long
Power supply:
from 110 to 240 V AC, tolerance +/- 10%
frequency from 48 to 62 Hz
Absorption from mains:
700 W max
Fuse:
T 10 A H, 5 x 20 mm
Dimensions:
570 x 277 x 720 mm (WxHxD)
Weight (approx):
~45 kg
Operating temperature:
10 to 35°C
Shipping temperature:
-15 to 55°C
Storage temperature:
-15 to 55°C
Humidity:
20% to 95% without condensation
Safety:
EN 60950
Portability:
considered “desktop equipment”
Electromagnetic compatibility:
EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
Transport:
IEC 68-2-31, IEC 68-2-32
16 TECHNICAL SPECIFICATION
