Progressive Turf Equipment Pro-Max 36 - Manual (Page 6)

6
SPECIFICATIONS
DESCRIPTION Pro-Max 36
Cutting Width
36’
Cutting Height 3/4” to 5”
Recommended PTO HP 80 to 110 (or 64% more than what is currently used)
Hydraulics
Requires 2 double acting outlets. One with float position.
Transport Width
13’
Height (folded)
13’
Length Pro-Max 36 only 13’2”.
Complete system with 22’ mower 29’8”.
Ground Clearance
8”
Deck Flexibility 25 degrees up 15 degrees down
Number of Tires Pro-Max 36 - 2 road wheels, 8 deck wheels.
Total system – 4 road wheels, 18 deck wheels
Mowing Capacity MPH 2
4
6
7.5
8.8 acres/hr
17.5 acres/hr
26 acres/hr
32.8 acres/hr
Assumes no stops or overlap
Weight 4600 lbs.
Tongue Weight 1400 lbs. in transport position
Tongue Weight 700 lbs. in mowing position
Paint Finish Electrostatically applied paint with oven baked finish
Deck Note: see TD-92 specifications for mower deck information
Frame Hollow structural steel tubing with supports at high stress
areas to achieve maximum strength.
Axles Two specially designed castors with 6000 lb. rating for
transport wheels
Wheels
6 bolt with 6” bolt circle
Tires
2 of P275/60SR 15” automotive style radials
Cylinders Wing lift – 2 of 3.5” by 24”
Screw Jack 5000 lb. top wind jack for easy hook-up
Main Gearbox 4 shaft gearbox with 1 3/8” – 6 spline shafts
PTO Shafts Telescoping, agricultural PTO driveshafts with proper safety
shields 1-3/8”-6 spline quick disconnect yoke on both ends
with ring lock collars
Input PTO Category # 6 H.D.
Deck PTO Category # 3 H.D.
