Progressive Turf Equipment Pro-Max 36 - Manual (Page 25)

25
CUTTING HEIGHT AND ADJUSTMENT:
Mower cutting height adjustment is made by removing the lynchpin from the top
of each castor stem (square or round) and corner support, and moving the spacers
either above or below support tube as required for your selected cutting height.
Be sure all adjustments are set the same.
When setting the cutting height on the Pro-Max 36, be sure to use
the wing safety chains. The chains are located in the box just below
and behind the main gearbox on the mower.
Two holes on frame to anchor the safety chain.
- Inside hole for blade change.
- Outside hole for cutting height change.
LOWERING THE WING DECKS:
Any time the wings are raised and work is being done on the decks, the wing
safety chains must be installed. Refer to the section on Maintenance.
When operating the PRO-MAX 36, the hydraulic control valve operating the
wings must be in FLOAT position. This will allow the wings to follow the contour
of the ground. If the valve is not in float, the mower will not cut evenly.
Mount chain
in top hole. Safety Chain
