2.6 Accessories Required But Not Supplied
Installation kit p/n STX100-IKC (crimp) is required to complete the installation. It
consists of the following:
STX100-IKC:
Quantity Description NAT Part #
1 D-min 25 Socket housing 20-21-025
25 MS Crimp Socket 20-26-901
1 25 Pin JVL Hood/Locklever 20-29-250
1 Vertical Mount Tray NTX-VT1
1 Base plate 50-08-026
1 TX Filter 54-04-001
6 6-32 Screw, Flathead 25-13-016
2.7 Installation Drawings
DRAWING REV. DESCRIPTION TYPE SERIAL #
STX100\306-0 1.00 STX100 Satcom System Block Diagram System Configuration All
STX100\000\403-1 1.10 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\403-2 1.10 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\403-3 1.10 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\403-4 1.11 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\403-5 1.11 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\403-6 1.00 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\403-7 1.01 STX100 Globalstar™ Satphone Transceiver Interconnect All
STX100\000\405-0 1.10 STX100 Globalstar™ Satphone Transceiver Connector Map All
STX100\000\634-0 1.00 Post Installation EMI Test Installation Approval Test Procedure All
STX100\000\922-0 1.20 STX100 Globalstar™ Satphone Transceiver Mechanical Up to 2048
STX100\000\922-0 1.30 STX100 Globalstar™ Satphone Transceiver Mechanical 2049 and up
NTX-VT1\922-0 1.00 Vertical Mount Tray Mechanical All
5404002\952-0 1.00 TX Filter Assembly Mechanical All
Section 2 ends after these Drawings
