Table 2-1 Example of Transmit Cable Calculations
Part Number Cable OD Bend Radius Min (1.35 dB) Max (2.15 dB) 1.6 GHz
Units Mil's Inches Feet Feet DB/Foot
ECS Cable
311201 317 1.59 20.1 32.1 0.067
310801 452 2.26 28.7 45.7 0.047
8C0500 630 5 45.0 71.7 0.030
PIC Wire&Cable
S55122 300 1.6 19.0 30.3 0.071
S22089 435 2.5 27.6 43.9 0.049
Table 2-2 Example of Receive Cable Calculations
Part Number Cable OD Bend Radius Min (1.50 dB) Max (8.50 dB) 2.5 GHz
Units Mil's Inches Feet Feet DB/Foot
ECS Cable
311901 195 1 8.1 45.9 0.185
311601 229 1.15 11.5 65.4 0.130
311501 229 1.2 13.9 78.7 0.108
PIC Wire&Cable
S86208 130 0.65 6.3 35.8 0.2375
S88207 130 0.65 6.5 37.0 0.230
S44191 195 1 7.6 43.1 0.197
S44193 195 1 8.2 46.6
0.1825
S67163 230 1.2 12.9 73.3 0.116
2.3.5
Antennas
Correct antenna placement and mounting is critical in order to achieve the best possible
performance. In general, keep all antennas as widely separated as possible and clear
of any large airframe obstructions.
Installation of the antenna should be in accordance with AC 43.13-1B, chapter 4,
section 4, and AC 43.13-2A chapter 3. If possible, the antenna should be located a
minimum of 8 feet from aircraft navigation receiver antennas and a minimum of 4 feet
from aircraft communications and ELT antennas.
Note: The STX100-000 antenna should be located a minimum of 6’ from the GPS
antenna, and MUST be top mounted (satellite view).
Avoid antenna locations that may become fouled with oil, water, fuel or dirt, as this will
degrade performance.
CAUTION:
Ensure that the unit is mounted in a location where the general population will
not approach within 8 inches (20cm) of the transmitting antenna. This distance
provides an additional safety margin for the product.
