STX100-000 Globalstar ™ Satphone Transceiver Manual SM67 Rev. 4.10
1.4.2
Physical Specifications
Depth 11.20" (284.5 mm) maximum
Height 7.25" (184.2 mm) maximum
Width 2.26" (57.4 mm) maximum
Weight 7.35 lbs (3.3 kg) maximum
Mounting Tray (NTX-VT1)
Material 5052-H32 Aluminum alloy (Top and Bottom Covers)
6061-T6 Aluminum alloy (all other pieces)
Finish Black anodized (exposed surfaces)
per MIL-A-8625 Type III Class 2
Clear chromate conversion (internal chassis and
connector/contact areas)
Connectors One 25-pin male D-subminiature with V5 locking H/W
Two TNC female bulkhead
Installation Kit STX100-IKC
1.4.3
Environmental Specifications
Temperature
(Operating) -30° C to +60° C
(Survival)
-40° C to +85° C
Altitude 50,000 ft
Humidity 95%
Shock DO-160D Cat. B
Vibration DO-160D Cat. (SM)
Qualification:
DO-160D Env. Cat. [A4]-BAB(SM)XXXXXXABBXXXLXXXX
Industry Canada Approval: IC:993B-STX100
FCC Approval: Verification to FCC Part 25
Compliance to FCC Part 15
