c) Check the operation of the VOL, HOLD, REDIAL and FLASH functions on the
PTA12.
d)
Request the ‘called party’ to place a call to the aircraft, and confirm ringer
operation and incoming call functions.
2.3.8.3
Power On Checks, Data
a) Following completion of the Voice tests, connect a laptop computer to the data
port on the STX100-000 (this assumes the data port connections are accessible
and allow for easy connection to the laptop).
b)
Using a terminal emulator program (i.e. HyperTerminal, TerraTerm, etc.) with the
serial port correctly set to communicate with the STX100-000 (19,200 baud, 8
Bit, 1 Stop Bit, No Parity), type AT . You should get an OK back from the
STX100-000, verifying the data port wiring is correct and that you can
communicate with the internal modem of the STX100-000.
Once you have verified connection with the modem, you can test the PPP connection
using TCP/IP. Confirm you have correctly set the modem and dial-up networking
connections, and that you have a working ISP before proceeding with the test.
2.3.9
Post Installation EMI Test
The purpose of this test is to identify any interference that the STX100-000 may cause
with existing aircraft systems. The STX100-000 should be tested in accordance with the
Installation Approval Test Procedure listed in section 2.7, and the test results
documented on the record sheets.
Upon satisfactory completion of all performance checks, make the required log
entries and complete the necessary Regulatory Agency paperwork before
releasing the aircraft for service.
2.4 Pilot Advisory Notice
The operating equipment associated with the STX100-000 Globalstar ™ Satphone
Transceiver equipment must be placarded, in clear view of the pilot, with the following:
SATPHONE NOT TO BE USED FOR ATC PURPOSES
DO NOT USE ON GROUND DURING REFUELING
2.5 Continued Airworthiness
Maintenance of the STX100-000 is ‘on condition’ only. Periodic maintenance of this
product is not required.
