EDVPV47-58 Power Vent System
Part No. XG0700 - 090909
f i r e f e a t u r e
CAUTION!
Due to its high operating temperatures, the appliance
should be located in a well ventilated area / space. See
the clearancespecifications on Page 8.
 Children and adults should be alerted to the hazards
of the high surface temperature, which could cause
burns or clothing ignition.
 Young children should be carefully supervised when
they are in the same room as the appliance.
 Clothing or other flammable materials should not be
placed on or near the appliance.
Introduction
Before You Begin
■ Minimum clearances 1” from vent to all combustible materials
must be maintained. Clearances listed in the fireplace’s Instal-
lation Operation and Maintenance Instructions supersede this
number.
CAUTION :
Ensure Perforated Air Holes in the New Pipe Adapter / Restrictor
are not Covered when installing New Pipe Connection.
CAUTION :
When cold air enters the warmer building interior, primarily at the
air intake end, condensation may occur on the exterior of the flex
pipe. To limit this condensation, install insulation over the last
twenty feet of flex pipe. Also, by sloping the last 20'-0" feet of flex
pipe downward toward the exterior of the building, elimination of
most of the condensation problems should occur. Ensure the ter-
mination is securely fastened, and sealed to the flex pipe. Fasten
the termination to exterior of the building with water tight sealant
and the appropriate fasteners.
General Information
This installation guide covers installation of the External Power Vent
System only. This system is designed to allow installation of gas fire-
places that cannot be done with a standard Direct Vent gas fireplace
installation.
Also, read through the fireplace's Installation Operation and Mainte-
nance Instructions, as it must also be adhered to.
Power Cord Harnesses:
EPVH10 -10 foot power cord and harness
EPVH20 -20 foot power cord and harness
EPVH30 -30 foot power cord and harness
EPVH40 -40 foot power cord and harness
EPVH50 -50 foot power cord and harness
EPVH60 -60 foot power cord and harness
EPVH70 -70 foot power cord and harness
EPVH80 -80 foot power cord and harness
EPVH90 -90 foot power cord and harness
EPVH100 -100 foot power cord and harness
Selecting and Installing the
Fireplace
When selecting a gas fireplace for use with the External Power Vent
System, take into consideration the various requirements and limita-
tions in the venting installation section for the following models:
Models Equipped with Hot Surface Ignition (HSI)
It is recommended that this system be used with a gas fireplace
equipped with a Hot Surface Ignition System. Because there is not a
pilot in this system, there is more flexibilty on venting requirements.
For example downward vertical vet runs are possible with an HSI
system, as outlined in the Venting Section.
Models Equipped with Millivolt/ Standing Pilot
If a standing pilot model must be used, then the millivot wiring har-
ness must be installed, see the Wiring Section for more information.
Also, downward vertical vet runs are not possible with a standing pilot
system, as outlined in the Venting Section.
Installation
Page 3
