Safety Alert Key
Page 3
XG0521 - 111214
Specifications
General Information
This installation guide covers installation of the External Power Vent
System only. This system is designed to allow installation of gas fireplaces
that cannot be done with a standard Direct Vent gas fireplace installation.
Only for use on R-Series, R-Series See-Through and RP-Series that
uses the 5/8 venting system.
ONLY USE WITH APPROVED FIREPLACES - see fireplace
installation manual.
Read through the fireplace's installation & maintenance manual, as it
must also be adhered to.
Power Cord Harnesses:
EPVH10 - 10 foot power cord and harness
EPVH20 - 20 foot power cord and harness
EPVH30 - 30 foot power cord and harness
EPVH40 - 40 foot power cord and harness
EPVH50 - 50 foot power cord and harness
EPVH60 - 60 foot power cord and harness
EPVH70 - 70 foot power cord and harness
EPVH80 - 80 foot power cord and harness
EPVH90 - 90 foot power cord and harness
EPVH100 -100 foot power cord and harness
Before Your Begin
For vent configurations and power vent locations,
refer to fireplace manual.
Pipe Dimensions PVHIN58-300 ............5"/8"
Pipe Dimensions TMHIN58-40 ..............5"/8"
Maximum Airflow: .........................300 CFM
Speed: .......................................... 2700 RPM
Power: ............................................Connect to fireplace control box
............................................ Refer to fireplace rating plate
