C-Series DV Gas Fireplace
Part No. XG0170 - 080610
Warning:
Read this manual before installing, operating or troubleshooting this
appliance. Please retain this owner's manual for future reference.
Congratulations!
Congratulations on selecting a Montigo gas fireplace, an elagent
and well designed gas fireplace built to your specifications. The
Montigo gas fireplace you have selected is designed to provide
the utmost in safety, reliability, and engineering standards.
As the owner of this new fireplace, you'll want to read and care-
fully follow all the instructions contained in this Installation,
Operations and Maintenance manual. Pay special attention to all
cautions, warnings, and Important warnings.
This owner's manual should be retained for future reference. We
suggest that you keep it with all your other important documents
and product manuals.
The information contained in this owner's manual, unless noted
otherwise, applies to all models, and gas control systems.
Your new Montigo gas fireplace will give you years of durable,
reliable use. Welcome to the Montigo family of gas fireplace
products.
Table Of Contents
Safety Alert Key:
• DANGER!
Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING!
Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION!
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE:
Used to address practices not related to personal injury.
•
Important:
Used to address practices not related to personal injury.
Congratulations
Safety Alert Key
Introduction .............................................................................. 3
Installation
Installing and Framing the Fireplace .............................. 4
Installing the Gasline ...................................................... 5
The Remote Switch ........................................................ 6
Direct Vent Installation ................................................... 5
General Venting Requirements ......................... 5
Terminations ...................................................... 6
Top Vent Venting Runs ................................7 - 9
Rear Vent Venting Runs ........................... 10 - 11
Finishing around the fireplace
Facing .............................................................. 12
Mantels and Surrounds ................................... 12
Wiring ..................................................................13 - 14
Installing Optional Fans................................................ 13
Removing and Installing the Door ................................ 15
Installing the Horizontal Trim ........................................ 15
Positioning the Logset .................................................. 16
Operation ..................................................................17 - 20
Maintenance ....................................................................20 - 22
Spare Parts ................................................................. 22
Warranty ................................................................................. 23
Appendix
A. Termination Locations .............................................. 24
B State of Massachusetts / Amendment .................... 25
Notes ..................................................................................... 26
