EDVRSPV Vertical Power Vent System
Part No. XG1302 - 120110
Warning:
Read this manual before installing, operating or troubleshooting this appli-
ance. Please retain this owner's manual for future reference.
Safety Alert Key:
• DANGER!
Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING!
Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION!
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE:
Used to address practices not related to personal injury.
•
Important:
Used to address practices not related to personal injury.
Table Of Contents
Important:
All dimensions, and design specifications are
subject to approval upon quotation of fire-
place and associated equipment.
Congratulations
Safety Alert Key
Table of Contents ..................................................................... 2
Specifications ............................................................... 2
Introduction ............................................................................... 3
Installation
General Information ..................................................... 3
Selecting and Installing the Fireplace ........................ 3
Dimensions ................................................................... 4
Vent Installation............................................................ 5
Power Vent Installation ...........................................5 - 7
Wiring ......................................................................7 - 9
Warranty ......................................................................... 10
Appendix
A. Termination Locations .......................................... 11
B State of Massachusetts / Amendment ................. 12
Motor Model Number: M2E068DF
Manufacturer : EBM Germany
Voltage: 110 Volts
Frequency: 50 Hz
Current draw: 1.41 Amp
Power consumption: 155 W
Speed: 2850 RPM
Maximum air movement: 400 CFM at zero restriction
Minimum air movement: 50CFM at 2.2" WC
Protection: Thermal switch
Bearings: Ball bearings
Specifications
