Remote control functions
The remote control buttons are used to send commands to the system. The descriptions below
reflect the standard configuration for this system. The buttons can be custom configured for the
user’s specific needs by the installer.
S
TANDARD CONFIGURATIONS BUTTON
The arming function is controlled by pressing this button for one second.
The panic feature is controlled by pressing this button for more than 5 seconds.
The disarming function is controlled by pressing this button for one second.
The panic feature is controlled by pressing this button for more than 5 seconds.
Silent Mode™ and an optional auxiliary function are controlled by pressing this button.
(Silent Mode™ works by pressing this button for less than one second before arming or disarming.
An optional auxiliary function, such as trunk release, can be controlled by pressing this button for 1.5 seconds.)
The auxiliary output controls:
The panic feature is controlled by pressing this button for approximately two seconds. (1)
&
An optional auxiliary convenience or expansion function that you have added
to your system can be activated by pressing these buttons simultaneously.
The auxiliary output controls :
&
An optional auxiliary convenience or expansion function that you have added
to your system can be activated by pressing these buttons simultaneously. (1)
The auxiliary output controls :
&
An optional auxiliary convenience or expansion function that you have added
to your system can be activated by pressing these buttons simultaneously.
The auxiliary output controls :
&
An optional auxiliary convenience or expansion function that you have added
to your system can be activated by pressing these buttons simultaneously. (1)
The auxiliary output controls :
(on rear of LCD remote) Use this button to select the vehicle to control from the remote. Also use this
button to configure response characteristics from the LCD remote (see Programming 2-Way Remote). (1)
(1) Not available with the 3-button remote control.
