Programming options – Directed Audio 2 Way Security and Conveniece System VSS-204TW User Manual

Page 27

Programming options

See your dealer for further details on the options listed below available with this system.

Automatic Engine Disable: Prevents the vehicle from being started even if the vehicle is not armed

after turning the ignition Off and exiting the vehicle.

Comfort Closure: Windows will close upon locking the vehicle.

Dual Sensor Trigger: If programmed On both the onboard and at least one of the optional

sensors need to be triggered within 1- second of each other for full alarm.

Forced Passive Arming: If passive arming is on and a door is left open the system will be armed

after 30-seconds.

High Security Disarm: If the system is triggered this feature allows the user to silence the siren and

reset the system to the armed state without having to visually check the system status.

Multi-level Arming: Allows bypassing of user selected alarm zones of the vehicle.

Grouped Arming: Allows bypassing of the group of alarm zones for warn-away, or both warn-

away and full alarm of the vehicle.

NOTE: In dual sensor mode, the LCD remote will report showing

both zones that tripped the alarm. The in-vehicle LED will flash to

indicate only the last sensor of the pair which tripped the alarm.

Panic with Ignition Off: Prevents the Panic button on the remotes from activating panic with

ignition On (not allowed in some states).

Parking Light Supervision: The parking lights will illuminate for 30-seconds after disarming the

system or turning the ignition off.

Remote Start Reporting: This channel 3 program option allows bypass of the security inputs that

would trigger an alarm when activating an added optional remote start system, but still retains a

high level of security.

Retained Accessory Power: This output from the security system can be connected to vehicle

accessories. After the ignition has been turned off, it will continue to supply power until a door

has been open.
