TABLE FOR THE CHOICE OF THE INJECTORS
LUBRICATION OF THE GAS TAPS
If the gas tap becomes stiff, it is necessary to dismantle it carefully and clean it with
petroleum spirit. Specialist high temperature resistant grease should be used to lubricate
the tap before replacing.
The operations must be carried out by an authorised person.
Test Point Pressure (kPa)
BURNER
Auxiliary (A)
Semi-rapid (SR)
Double-ring (DR)
Natural gas
1,0
LPG-Propane
2,75
Nominal
Power
[kW]
Reduced
Power
[kW]
0,9
0,25
Injector
Orifice Dia.
[mm]
Primary air
shutter
opening
[mm]
Injector
Orifice Dia.
[mm]
Primary air
shutter
opening
[mm]
1,7
3,4
0,44
0,85
0,83
1
0,5
3
1,15
4
0,67
6
1,6
15
0,92
Fully open
Fish burner (FB)
N=2,8
LPG=3,06
0,85
1,42
15
0,90
Fully open
BURNERS
Auxiliary (A)
Semi-rapid (SR)
Double-ring (DR)
3
Air necessary for combustion [m /h]
2,00
3,80
6,90
3
INCREASE OF AIR NECESSARY FOR GAS COMBUSTION (2 m /h x kW)
Fish burner (FB)
7,10
