ASSEMBLING THE BACKGUARD
Before assembling remove any protective film/adhesive tape.
The backguard B can be found on the cooktop.
[
Check that the side supports S and D are correctly mounted into the backguard B (see
fig. 20).
[
Insert the backguard group into the support guides in the cooker.
[
The backguard can be removed for cleaning or fixed with a screw through the hole C.
Fig. 20
D
B
C
S
