Kleenmaid FEG900X User Manual
Page 32
32
Fig. 31
G
V
B
E
D
D
E
B
CONVERSION PROCEDURE
INJECTORS REPLACEMENT
This appliance is suitable for use with Natural Gas or LPG-Propane (check the “gas type”
sticker attached to the appliance). A label stating the type of gas used after replacing the
injectors must be attached at the rear of the appliance, in proximity of the gas inlet
connection. The nominal gas consumption and injector size details are provided in table at
page 35.
To replace the injectors it is necessary to lift the cooktop and proceed as follows:
[
Remove the backguard “G” or remove the lid “A” (fig. 31 and 32).
[
Remove pan supports and burners from the cooktop.
[
Unscrew the screws “B” and remove the sockets (fig. 31 and 32).
[
Unscrew the two screws “D” and remove the two side trims and joints pulling upwards.
