ELECTRICAL CHARACTERISTICS CURVES
76
78
80
82
84
86
88
90
0.8 1.0 1.2 1.4 1.6 1.8
OUTPUT VOLTAGE (V)
EFFI
CI
ENCY (
%
)
36Vin 48Vin 75Vin
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
0.8 1.0 1.2 1.4 1.6 1.8
OUTPUT VOLTAGE (V)
P
O
WE
R
D
IS
S
IP
A
T
ION
(W)
36Vin 48Vin 75Vin
Figure 5: Efficiency vs. output voltage for minimum, nominal,
and maximum input voltage at 25°C. (Iout=80A)
Figure 6: Power dissipation vs. output voltage for minimum,
nominal, and maximum input voltage at 25°C. (Iout=80A)
0.0
1.0
2.0
3.0
4.0
5.0
6.0
30 35 40 45 50 55 60 65 70 75
INPUT VOLTAGE (V)
IN
PUT CURREN (
A
) Io=80A Io=48A Io=8A
Figure 7: Typical input characteristics at room temperature Figure 8: Turn-on transient at full rated load current (resistive
load) (1 ms/div). Top Trace: Vout; 1V/div; Bottom Trace:
ON/OFF input: 2V/div
