Page 13
DS_H48SR1R880_06272006
PART NUMBERING SYSTEM
H 48 S
R 1R8
80 N R
F
A
Form
Factor
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin
Length
Option
Code
H- Half Brick
48-
36V~75V
S- Single
R- Single
Board
1R8- 1.8V
80- 80A
N- Negative
P- Positive
R- 0.170”
N- 0.145”
K- 0.110”
F- RoHS 6/6
(Lead Free)
A - Standard
Functions
MODEL LIST
Part Number
INPUT
OUTPUT
EFF @ 100% LOAD
H48SR1R860NRFA
36V~75V
3.7A
0.8V – 1.9V
60A
88%
H48SR1R880NRFA
36V~75V
5.0A
0.8V – 1.9V
80A
89%
H48SR3R360NRFA
36V~75V
6.4A
1.45V – 3.6V
60A
90%
Please contact us for modules with fixed output voltages.
CONTACT:
www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
Europe:
Telephone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
Asia & the rest of world:
Telephone: +886 3 4526107 x6220
Fax: +886 3 4513485
Email:
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for
its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license is
granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
.
