Technical data
16 · G&D Dynamic-UserCenter 32
Technical data
Interfaces
Dynamic Ports:
32 × RJ45 socket
Network connector:
2 × RJ45 socket
RS 232 interface:
without function
RS 485 interface:
without function
Division of
Dynamic Ports
Minimum size of a group:
1 CPU port and 2 Cluster ports
Max. number of groups:
10
Default:
8 CPU ports (groups) with
3 Cluster ports each
Main power supply
Type:
Internal power pack
Connector:
1 × IEC plug (IEC-320 C14)
Power input:
100 - 240 VAC/60-50Hz; 0.8A-0.3A
Redundant
power supply
Type:
Internal power pack
Connector:
1 × IEC plug (IEC-320 C14)
Power input:
100 - 240 VAC/60-50Hz; 0.8A-0.3A
Housing
Material:
Anodised aluminium
Dimensions (W × H × D):
435 × 44 × 211 mm (Desktop)
19” × 1U × 211 mm (Rackmount)
Weight:
Approx. 3 kg
Operational
environment
Temperature:
+5 to +40 °C
Air humidity:
< 80%, non condensing
Conformity
CE, RoHs
