Installation
8 · G&D Dynamic-UserCenter 32
5. You can also adjust the current port layout or one of the frequently used configu-
rations as shown in the table below.
6. Click Ok to save any changes.
7. Click the Logout icon (see figure on the right) to leave the active
session of the web application.
NOTE: Select several ports by simultaneously pressing the left mouse key and
Shift or Ctrl .
NOTE: You can also carry out the actions shown in the table via drag & drop.
Carry out action in graph Carry out action in table
TO CREATE A NEW PORT GROUP
 Right-click an unassigned port that
you want to use as CPU port of the
new group.
 Select New group from the context
menu.
 In the left column, click the CPU
port you want to create for the new
port group.
 Click .
TO ASSIGN A CLUSTER PORT TO A PORT GROUP
 Right-click an unassigned port that
you want to add as Cluster port of a
group.
 Select Assign from the context
menu.
 Select the CPU port in whose group
you want to add the Cluster port.
 In the left column, click the Cluster
port you want to add.
 In the right column, click the
group name or a port of the group
to which you want to add the Clus-
ter port.
 Click .
TO DELETE A CLUSTER PORT FROM A PORT GROUP
 Right-click the Cluster port you want
to delete from the group.
 Select Delete from group from the
context menu.
 In the right column, click the Clus-
ter port you want to delete from the
group.
 Click .
TO DELETE A GROUP
 Warning: All ports of a port group are deleted.
 Right-click the CPU port whose
group you want to delete.
 Select Delete group from the context
menu.
 In the right column, click the CPU
port whose group you want to
delete.
 Click .
NOTE: Click Print to print a detailed list of all ports.
IMPORTANT: After you change the port assignment, the matrix switch reboots.
